Indoor RU
· Simplified construction, lighter and more flexible
· Plug and play, easy to installation
· Shopping mall / multi-floor coverage
· LTE mode support 4x4MIMO,256QAM, 512users per cell
· NR mode support 4x4MIMO, 256QAM,1200 users per cell
Features
Model
CRAI RU 4x250mW indoor RRU
Frequency band
5G: N41/N78
4G+5G: B3+N41
Bandwidth
4G: 5/10/20 MHz
5G: 100MHz
IBW
100Mhz
OBW
4G: 40Mhz; 5G: 100Mhz
Max Output Power
24 dBm / channel x 4 channels
Antenna
Internal antenna
Antenna port
4T4R/2T2R
Rx Sensitivity
4G: -102 dBm; 5G: -94dBm
Fronthaul
1 x 10GE optical fiber interface (SFP+), LC
1 x 10GE Ethernet interface (RJ-45)
Power supply
-40.5 to 57 VDC, Nominal -48VDC or
48V PoE power supply, comply with IEEE 802.3at standard
Power consumption
Typical 39W, maximum 45W
Dimension
8.1 x 8.1 x 2.3 inches; 205 X 205 X 58 millimeters
Weight
6.6 lbs / 3.0kg
Installation
Ceiling or wall mount
MTBF
≥ 150000 hours
MTTR
≤ 1 hour
Temperature
23°F to 104°F / -5°C to 45°C
Humidity
5% to 95%
